5mp IP Network Varifocial Lens Bullet Weatherproof with IR
Sibell IPOB-SB5IRVA 5mp IP Network Varifocial Lens Bullet Camera for video security provides 5 Mega Pixel real-time resolutions at 30fps. a 3.6 – 10mm varifocal zoom lens to zoom in and capture intimate details. 3D DNR Wide Dynamic Range (digital WDR) and IR Cut Filter (ICR) True Day/Night to deliver quality imagery in any type of lighting environment. Starlight feature set to allow for color vision at night as well as Night Vision IR distance up to 95 – 160 Feet. POE Power supply and IP66 Rated. All Sibell IP cameras have ONVIF allowing for integration with other ONVIF platforms.
Key Features:
- 5 Mega Pixel ( 2592 x 1944 )
- H.265 video encoding
- 3.6~10mm Lens
- ICR auto switch, true day / night
- 95 ~ 160 feet IR night view distance
- Starlight Camera: See color at Night
- 3D DNR, digital WDR, HLC, BLC, defogging
- Supports 8 ROI codings
- Supports local CVBS video output and Two-way audio
- Supports PoE power supply
- Supports smart phone, iPad, remote monitoring
- One gigabit ethernet network port, 10m / 100m / 1000m
- SD card local storage, up to 64 GB
Description
Model#: IPOB-SB5IRVA 5mp IP Network Varifocial Lens Bullet |
|
| Camera | |
| Image Sensor | 1/ 1.8 “CMOS |
| Image Size | 2592 x 1944 |
| Electronic Shutter | 1 / 25 s ~ 1 / 100000 s |
| Min. Illumination | 0.01 lux @F1.2,AGC ON; 0 lux with IR |
| Lens | 3.6~10mm |
| Day & Night | ICR |
| Wide Dynamic Range | Digital WDR |
| Digital NR | 2D / 3D DNR |
| Angle Adjustment | Pan : Any Angle |
| Image | |
| Video Compression | H.265/ MJPEG |
| Resolution | 5MP ( 2592 × 1944), 4MP ( 2560×1440 ), 3MP ( 2304×1296 ),1080P ( 1920×1080 ), 720P ( 1280×720 ), D1, CIF, 480×240 |
| Multi-stream | 5MP(1~30fps) / 2560 × 1440 (1~30fps) 1080P (1~30fps) / 720P(1~30fps) |
| D1(1~60fps) / CIF(1~30fps) | |
| D1(1~30fps) / CIF(1~30fps)/ 480 × 240(1~30fps) | |
| Bit rate | 16 Kbps ~ 40 Mbps |
| Encode Mode | VBR / CBR |
| Quality | Five levels under VBR; Freely adjustable under CBR |
| Image Settings | ROI, Saturation, Brightness, Chroma, Contrast,
Wide Dynamic, Sharpen, NR,etc. Adjustable through client software or web browser |
| Audio Compression | G.711A / U |
| ROI | Support independent ROI configuration of each stream |
| Interfaces | |
| Network | Gigabit ethernet network port ( RJ45 x 1 ), 10M / 100M / 1000M self-adaptive |
| Audio | Two-way audio (MIC IN × 1, MIC OUT x 1) |
| Video Output | CVBS video output ( BNC × 1 ) |
| Storage Card | Support SD card, up to 64GB |
| RS485 | Yes |
| Alarm | Input: 1ch Output: 1ch |
| Functions | |
| Remote Monitoring | IE browsing,CMS remote control |
| Online Connection | Support simultaneous monitoring for up to 10 users;
Support multi-stream real time transmission |
| Protocol | TCP / IP, UDP, DHCP, NTP, R Protocol TSP, PPPoE, DDNS, SMTP, FTP |
| Interface Protocol | ONVIF, GB-T / 28181-2011 |
| Storage | SD card local storage, network remote storage |
| Smart Alarm | Motion Alarm, Sensor Alarn |
| PTZ | RS485 x 1 |
| PoE | Yes |
| IR Distance | 95 ~ 160ft (30-50m) |
| Water-proof | IP66 |
| Other | |
| Power Supply | DC 12V / PoE |
| Power Consumption | < 3W |
| IR Consumption ON | < 7.5W |
| Operating Environment | – 20 °C ~ 50 °C,10 % ~ 90 % humidity |
| Dimensions ( mm ) | ø 109 × 284 |
| Weight ( net ) | 1132g |
Accessories
Compatible Camera MountsPart Number: JB-SB-BR
 |
Part Number: JB-SB-UNIR
 |
Documents
Download “IPOB-SB5IRVA Specsheet”
IPOB-SB5IRVA-Specsheet.pdf – Downloaded 678 times – 370.64 KBDownload “IPOB-SB5IRZA Quickstart Guide”
IPOB-SB5IRZA-QSG.pdf – Downloaded 726 times – 1.09 MBDownload “Sibell 5MP user Manual”
Sibell-5MP-user-manual.pdf – Downloaded 706 times – 2.59 MBYou must be logged in to post a review.
