3mp IP Network Bullet Camera Weatherproof with IR
Sibell IPOB-SB3IREV 3mp IP Bullet Camera for video security provides 3 Mega-Pixel real-time resolutions at 30fps. (2048 x 1536). This 3mp IP Bullet Camera provides a feature set including ICR auto switch, true day / night, 3D DNR, and Digital Wide Dynamic Range. The Lens is manual varifocal 2.8-12mm adjustable zoom. The Sibell IPOB-SB3IREV is IP66 Rated weatherproof for indoor or outdoor use and all Sibell IP cameras have ONVIF allowing for integration with other ONVIF platforms. Sibell IP Cameras work seamlessly with Sibell Recorders.
Key Features:
- 3 Mega Pixel ( 2048 x 1536 )
- Max. Resolution: 2048 x 1536
- ICR auto switch, true day / night
- 33 ~ 66 feet IR night view distance
- 3D DNR, digital WDR
- ROI coding
- Supports PoE power supply
- Supports smart phone, iPad, remote monitoring
- Supports three streams
Description
IPOB-SB3IREV 3mp IP Bullet Camera |
|
| Camera | |
| Image Sensor | 1 / 3 “CMOS |
| Image Size | 2688 × 1520 |
| Electronic Shutter | 1 / 25 s ~ 1 / 30%000 s |
| Auto Iris | Fixed Iris |
| Min. Illumination | 0.05 lux @F1.2,AGC ON; 0 lux with IR |
| Lens | 3.3 ~ 12 mm @F1.4, angle of view: 80° ~ 38° |
| Lens Mount | ɸ 14 |
| Day & Night | ICR |
| Wide Dynamic Range | 120dB |
| BLC/ HLC/ Defogging | Yes |
| Digital NR | 2D/3D DNR |
| Angle Adjustment | Any Angle |
| Image | |
| Video Compression | H.265 / H.264 / MJPEG Main Profile @Leve4.1 High Tier |
| Resolution | 4MP ( 2592×1520 ), 2K ( 2560×1440 ), 3MP ( 2304×1296 ),
1080P ( 1920×1080 ), 720P ( 1280×720 ), D1, CIF, 480×240 |
| Main stream | 60Hz : 4MP( 1 ~ 30fps ) / 2K ( 1 ~ 30fps ) / 3MP( 1 ~ 30fps ) / 1080P( 1 ~ 30fps ) / 720P( 1 ~ 30fps ) 50Hz : 4MP( 1 ~ 25fps ) / 2K( 1 ~ 25fps ) / 3MP( 1 ~ 25fps ) / 1080P( 1 ~ 25fps ) / 720P( 1 ~ 25fps ) |
| Bit rate | 64 Kbps ~ 10 Mbps |
| Encode Mode | VBR / CBR |
| Quality | Five levels under VBR; Freely adjustable under CBR |
| Image Settings | ROI, Saturation, Brightness, Chroma, Contrast,
Wide Dynamic, Sharpen, NR,etc. adjustable through client software or web browser |
| Audio Compression | G711A / U |
| ROI | Each ROI to be configured separately |
| Interfaces | |
| Network | RJ45 |
| Audio | MIC IN × 1 |
| Video Output | CVBS video output ( BNC × 1 ) |
| Functions | |
| Remote Monitoring | IE browsing,CMS remote control |
| Online Connection | Support simultaneous monitoring for up to 10 users; Support multi-stream real time transmission |
| Protocol | TCP / IP, UDP, DHCP, NTP, RTSP, DDNS, SMTP,FTP |
| Interface Protocol | ONVIF, GB-T/28181-2011 |
| Storage | Network remote storage |
| Smart Alarm | Motion Alarm |
| PoE | Yes |
| IR Distance | 65-98ft (20~30m) |
| Water-proof | IP66 |
| Other | |
| Power Supply | DC 12V / PoE |
| Power Consumption | < 2.5W |
| IR Consumption ON | < 6W |
| Operating Environment | – 20 °C ~ 50 °C,10 % ~ 90 % humidity |
| Dimensions | ɸ 3.5in × 9in ɸ 87 × 219 |
| Weight ( net ) | 636g (1.5lbs) |
| Installation | Wall mounting, pendent mounting |
Accessories
Compatible Camera Mounts Part Number: JB-SB-BR
Documents
Download “IPOB-SB3IREV- Specsheet”
IPOB-SB3IREV-specsheet.pdf – Downloaded 226 times – 232.73 KBDownload “IPOB-SB3IREV - Quick Start Guide”
IPOB-SB3IREV-QSG.pdf – Downloaded 226 times – 1.31 MBDownload “IPOB-SB3IREV- Manual”
IPOB-SB3IREV-Manual.pdf – Downloaded 248 times – 1.93 MBYou must be logged in to post a review.
